Description

UNIMAT LATHE FROM OSBORNS

The Unimat Classic is a small benchtop all in one machine and fantastic value. Made in Austria

  • Wood Turning Lathe
  • Sander
  • Milling Machine
  • Metal Lathe
  • Bench Drill
  • Jigsaw

Wood Turning lathe enables elaborate pieces to be produced in a wide variety of woods. With a distance between centres of 135mm (which can be expanded to 324mm) and a maximum centre height of 25mm (extendable to 50mm with optional part # 162-036). The wood lathe smoothly turn a wide range of parts.

Sander. The sanding disc provides the perfect finish to your parts after cutting and shaping. The sander can also be detached for hand held use. Disc size: 50mm.

Milling (horizontal and verticle options). The fittings provided allow for Horrizontal and verticle milling in woods, plastics, metals and many other materials. An HSS milling cutter is included, but you can use virtually any commercially available milling cutters up to a fixing diameter of 6mm. Mill Data: Longtitudinal travel:50mm. Cross travel: 30mm (expandable with optional accessories).

Metal Turning Lathe: Turn soft metals like a professional toolmaker. Longtitudinal and Cross Slides with mm scaled handwheels allow for precise work to an accuracy of 0.03mm! Built with the same quality components as an expensive lathe the Unimat 1 allows the user to produce fine items such as axles, gears, couplings, rims and pulleys. (capacities as per wood turning lathe data).

Bench Drill: Using 3 precision slides, 2 of which can rotate through 360 degrees, the bench drill is capeable of precise drilling in every conceivable angle. The drill unit can also be removed for hand held use. Drill size capacity: 0.5 to 6mm. Table size: 85 x 50mm. Maximum height of working area: 120mm (option expandable).

Jigsaw: The powerful Jigsaw can be used with plywood, balsa, plastics and thin sheets of metal. It has a cutting capacity of 12mm in ply and  7mm in solid timber. Ideal for fretwork, cutting out windows and doors, trimming off PCBs etc. etc. Blade Stroke: 4mm. The Jigsaw uses very short strokes for precise cutting but only vibrates the skin if touched so will not cut you. It is therefore ideal for use by a supervised child. Table size: 90 x 90mm.

The set includes comprehensive instructions plus a DVD

and thats not all! The Unimat Classic is just the start of your home workshop. There are many optional accessories to expand the system still further to customize your requirements.

The product also comes with a five year warranty.

Overseas shipping rates vary greatly with this product and the postage rate shown cannot be guaranteed. We are always happy to quote for any destination prior to you placing an order
